The innovative design of the Optidisc Elite cutterbar offers exclusive differential disc spacing.

1. Less Distance for a Clean Cut - Narrower spacing at diverging discs provides greater knife overlap, which results in a clean cut, even when the grass is short or light.

2. More Distance for Easy Crop Passage - Wider spacing at converging discs provides more space for the crop to pass. Cut crop is quickly carried away from the cutting area, greatly improving the cut quality.

The Fast-Fit® quick-release knife system allows an operator to rapidly change out cutting knives with the use of a simple tool, yet still retain optimum cut quality and knife life. With Fast-Fit, an operator can achieve up to 50% time savings over a standard system.

Disc bearing stations are attached by bolts that pass through the entire cutterbar. This is an exceptionally strong and secure attachment with no risk of mount being torn out of the cutterbar in case of shocks. The disc drive pinion is held precisely in place, all resulting in excellent reliability and reduced maintenance costs.

Gear-to-Gear Power Transmission:

Gear-to-gear power transmission, a staple of all KUHN disc mowers, allows for maximum power to be transferred through all gears in the cutterbar. Unlike other gear cutterbars, equal sized gears throughout reduces torque on the gear teeth and leads to unsurpassed reliability and longevity.

• Protectadrive® Safety: Every minute saved during the hay season is precious. Ultimate protection, from the externally removable Protectadrive disc bearing stations, provides maximum reliability and quick service. In the event of an impact between a disc and an obstacle, the shaft holding the disc can shear just above the bearing. This is thanks to its carefully dimensioned shear groove. As a result, the gear teeth are protected.

• Extra Rigidity Where it Counts: Disc bearing stations are attached by bolts that pass through the entire cutterbar. This is an exceptionally strong and secure attachment with no risk of mount being torn out of the cutterbar in case of shocks. The disc drive pinion is held precisely in place, all resulting in excellent reliability and reduced maintenance costs.

• Gear-to-Gear Power Transmission: Gear-to-gear power transmission, a staple of all KUHN disc mowers, allows for maximum power to be transferred through all gears in the cutterbar. Unlike other gear cutterbars, equal sized gears throughout reduces torque on the gear teeth and leads to unsurpassed reliability and longevity.

Lift-Control is much more than just a suspension system with a nitrogen accumulator replacing the traditional spring. The main advantage of the Lift-Control system is derived from the exclusive way in which kinetic forces that act on the cutterbar are utilized. KUHN engineers have succeeded in making a dynamic suspension system, as opposed to the passive system most commonly used.

With the Lift-Control system, as the force exerted on the cutterbar increases, the suspension system automatically lightens the cutterbar. The greater the force, the lighter the cutterbar.

Benefits include:

• Constant ground pressure

• Non-stop safety breakaway

• Excellent terrain following

• Less soil in the crop

• Minimize torn up turf

No farmer can afford to damage his mower during the peak of the season because of an unnoticed obstacle or maneuvering error. On the new rear units, the mowing unit pivots rearward around the bracing pin when hitting and obstacle. In this moment, oil is transferred toward the suspension cylinder. The resulting pressure increase facilitates the mowing unit raising to clear the obstruction. Return to the initial working position is carried out nonstop.

For a clean cut on slopes and bends, the overlap between the front and rear units can be adjusted hydraulically between 16.5” and 24.4” (depending on the model combination) – even while driving. This is a real benefit for tractors with wide wheel spacing or large wheels.

The merger on the mower offers the operator more diversity in windrow placement. The wide merger conveyor allows the crop to be easily and gently transferred into the windrow. The merger conveyor belt can be angled and has individual conveyor lift abilities. No tools are needed for belt tensioning adjustments.

The DigiDry® finger conditioner provides consistent drying of grass and legume crops in various conditions with little maintenance. Wide rotor, fingerstyle conditioning increase crop-on-crop rubbing to strip off the waxy cuticle helping the steams dry at the same rate as the leaves. The built-in breakback feature normally protects against damage from rock and other foreign materials.

The direct drive design to the conditioner provides easy access for servicing and fully eliminates belts. Reliability is greatly improved when working in longer crops such as ryegrass.

On encountering an obstacle, the KUHN FlexProtect™ side shields bend without breaking or damaging the mower. After the obstacle’s passage, the side shield automatically returns back to its original shape.

Machine management via ISOBUS controls can be connected to either the tractor terminal or any AEF certified terminal. Optional CCI 800 or CCI 1200 can be purchased for screen interfaces common to other machines, operators will find them easy to read and user-friendly.

For easier operation, operators can use the ISOBUS certified AUX-N Joystick. Operators can take advantage of functions such-as the GO/END function to headlands, which allows the machine to automatically raise and lower into working positions at headland turns. Management of the merger functions, Lift-Control ground pressure, and mowing unit lift. The interface also allows the operator to monitor the center gearbox performance and temperatures, along with conveyor belt rotation from the comfort of the cab. Two standard work lights are also mounted on the mower conditioner for better visibility when operating into the night. The lights are also controlled through the ISOBUS system.
